HOME > 제품소개 > 제품정보


MR8827
멀티채널 고속 레코더
(Analog 32ch + Logic 32ch)
제품번호 : MR8827
제 품 명  : MEMORY HiCORDER
제품분류 : 레코더




(아날로그 32ch + 로직 32ch) ~ (아날로그 28ch + 로직 64ch) 입력 가능
모든 채널 20MS/s 동시 샘플링
모든 아날로그 채널이 절연되어 안전한 측정 가능
총 512M-words의 대용량 메모리 탑재
동시에 매우 낮은 전압에서 높은 전압 다양한 시스템 신호를 측정

  Number of channels [16 analog input modules]: 32 analog channels +32 logic channels
[14 analog input modules + 2 logic input modules]: 28 analog channels + 64 logic
* For analog modules, channels are insulated vs. each other and vs. unit ground.
For logic modules and integrated standard logic channels, all channels use the unit ground.
  Measurement ranges (20 div full-scale) [Analog unit 8966]: 5 mV/div to 20 V/div, 12 ranges, resolution : 1/100 of range (using 12-bit A/D)
[High resolution unit 8968]: 5 mV/div to 20 V/div, 12 ranges, resolution : 1/1600 of range (using 16-bit A/D)
[Digital voltmeter unit MR8990]: 100 mV f.s. to 1000 V f.s., 5 ranges, resolution : 1/1000,000 of range (using 24-bit A/D)
  Max. allowable input 500 V DC (using the MR8990), 400 V DC (using the 8966/8968)
  Frequency characteristics DC to 5 MHz (-3 dB, using the 8966), DC to 100 kHz (-3 dB, using the 8968), N/A (using the MR8990)
  Time axis (Memory function) 5 μs to 5 min/div, 26 ranges, at 100 points/div resolution
  Measurement functions Memory (high-speed recording), Recorder (real-time recording), X-Y recorder, FFT
  Other functions Numerical calculation, Waveform processing, Waveform judgment (at Memory, or FFT function)
  Memory capacity 128M-words/ch (using 4 Analog channels) to 16M-words/ch (using 32 Analog channels), Total capacity 512MW memory
  Data storage media USB memory stick, CF card, Built-in SSD unit (option, 128GB) *Approx. 125 sec. when saving 100 MB of data
*Data of 100 MB in size can record 16,000 div waveforms across 32 channels.
  Printing [Built-in A4-size printer option]: 216 mm (8.50 in) × 30 m (98.43 ft), thermal paper roll, Recording speed : Max. 50 mm (1.97 in)/s
  Display 10.4 inch TFT color LCD (SVGA, 800 × 600 dots)
  External interfaces LAN: 100BASE-TX
USB 2.0 series A receptacle 2 port (for USB memory, mouse)
USB 2.0 series B receptacle (for communication to PC, mass storage)
  Power supply 100 to 240 V AC, 50/60 Hz (220 VA max., when using printer: 350 VA max.)
  Dimensions and mass 401 mm (15.79 in)W × 233 mm (9.17 in)H × 388 mm (15.28 in)D (including protruding parts except handle), 12.6 kg (444.4 oz) (main unit only)
  Accessories Instruction manual ×1, Power cord ×1, Application disk (CD-R) ×1, Input cord label ×1, Printer paper ×1 (when ordering printer unit), Roll paper attachment ×2 (when ordering printer unit)




Printer options

RECORDING PAPER
9231


PRINTER UNIT
U8350

Storage media

PC CARD 1G
9729


PC CARD 2G
9830


PC CARD 512M
9728


SSD UNIT
U8330

Input modules

ANALOG UNIT
8966


TEMP UNIT
8967


HIGH RESOLUTION UNIT
8968


STRAIN UNIT
8969


FREQ UNIT
8970


CURRENT UNIT
8971


DC/RMS UNIT
8972


LOGIC UNIT
8973


DIGITAL VOLT METER UNIT
MR8990


CONVERSION CABLE
9769

INPUT CORD (A)

CONNECTION CORD(600V Max)
L9790


ALLIGATOR CLIP
L9790-01


CONTACT PIN
9790-03


GRABBER CLIP
9790-02

INPUT CORD (B)

CONNECTION CORD(300V Max)
L9198


GRABBER CLIP
9243


CONNECTION CORD
L9197

INPUT CORD (C)

10:1 PROBE
9665


100:1 PROBE
9666

INPUT CORD (D)

AC ADAPTER
Z1008


DIFFERENTIAL PROBE
P9000

INPUT CORD (E)

TEST LEAD
L2200

Other options for Input

CONNECTION CORD(BNC-BNC)
L9217


CONVERSION ADAPTER
9199

Logic signal measurement

LOGIC PROBE
9320-01


LOGIC PROBE
MR9321-01


LOGIC PROBE
9327


CONVERSION CABLE
9323

Up to 200 A (High precision)

CLAMP ON SENSOR
9272-10


CLAMP ON SENSOR
CT6862


AC/DC CURRENT PROBE
CT6841


CLAMP ON SENSOR
CT6863


AC/DC CURRENT PROBE
CT6843

Up to 500 A (High precision)

UNIVERSAL CLAMP ON CT
9279


AC/DC CURRENT SENSOR
9709

POWER SUPPLY

CONNECTION CORD(BNC-BNC)
L9217


SENSOR UNIT
9555-10

Up to 30 A (High speed)

CLAMP ON PROBE
3273-50


CLAMP ON PROBE
3276

Up to 150 A (High speed)

CLAMP ON PROBE
3274

Up to 500 A (High speed)

CLAMP ON PROBE
3275

100 A to 5000 A (Medium speed)

CLAMP ON AC/DC SENSOR
CT9693


CLAMP ON AC/DC SENSOR
CT9692


CLAMP ON AC/DC SENSOR
CT9691


AC FLEXIBLE CURRENT SENSOR
CT9667

LEAK CURRENT

OUTPUT CORD
9094


CONVERSION ADAPTER
9199


AC ADAPTER
9445-02


AC ADAPTER
9445-03

500 A to 1000 A

CLAMP ON PROBE
9018-50


CLAMP ON PROBE
9132-50

PC Software

WAVE PROCESSOR
9335


LAN CABLE
9642


LAN COMMUNICATOR
9333
