HOME > 제품소개 > 제품정보


MR8875
사용자 편의를 배려한 디자인
제품번호 : MR8875
제 품 명  : MEMORY HiCORDER
제품분류 : 레코더



* 본제품은 태신상사 기술영업사원과 상담이 필요합니다.
  제품데모도 가능하오니 문의바랍니다.(문의처는 홈페이지 하단참조)
Number of input units Up to 4 slots
Number of channels Max. 16 analog channels (Max. 60 channels when using the MR8902) + standard 8 logic channels + 2 pulse channels
Note: For analog units, channels are isolated from each other and from the MR8875's GND. For CAN unit ports or standard logic terminals or standard pulse terminals, all channels have common GND.
Measurement ranges
(20 div full-scale)
5 mV to 10 V/div, 11 ranges, resolution : 1/1250 of range (when using the MR8901)
Max. rated voltage Between terminals: 150V DC
Between terminal to earth: 100V AC, DC (when using the MR8901)
Frequency characteristics DC to 100 kHz (-3dB, when using the MR8901)
Time axis 200 μs to 5 min/div, 21 ranges, sampling period: 1/100 of range, External sampling possible
Max. sampling rate [When using MR8901] 500 kS/second (2 μs period, all channels simultaneously)
[When using MR8902] 10 msec (all input channels are scanned at high speed during every recording interval)
[When using MR8903] 200 kS/second (5 μs period, all channels simultaneously)
External sampling: 200 kS/second (5 μs period)
Measurement functions High-speed function (high speed recording)
Storage memory capacity Total 32 M-words (memory expansion: n/a, 8 MW each input unit)
Note: 1 word = 2 bytes, therefore 32 Mega-words = 64 Mega-bytes.
Note: Storage memory can be allocated depending on the number of channels used at each input unit
Removable storage SD Card slot × 1, USB 2.0 memory × 1
Display 8.4-inch SVGA-TFT color LCD (800 × 600 dots)
Communication interfaces LAN: 100BASE-TX (DHCP, DNS supported, FTP server/ client, WEB server, send E-mail, command control)
USB: USB2.0 compliant, series mini-B receptacle ×1 (setting / measure with communication command, or file transfer SD card to PC)
Power supply 1) AC ADAPTER Z1002: 100 to 240 V AC (50/60 Hz), 56 VA
2) BATTERY PACK Z1003: 7.2 V DC, 36 VA, continuous operation times;: 1 hour with back light ON (AC adapter has priority when used in combination with battery pack) , Charges while installed in the MR8875, recharging time: 3 hours
3) External DC Power: 10 to 28 V DC, 56 VA, (please contact your HIOKI distributor for connection cord)
Dimensions, mass 298 mm (11.73 in) W × 224 mm (8.82 in) H × 84 mm (3.31 in) D, 2.4 kg (84.7 oz), (excluding input units and the BATTERY PACK Z1003)
Reference data: 3.47 kg/ 122.4 oz (including the MR8901 ×4 units and the BATTERY PACK Z1003)
Supplied accessories Instruction Manual ×1, Measurement Guide ×1, AC ADAPTER Z1002 ×1, Protection sheet ×1, USB cable ×1, Shoulder Strap ×1, Application Disk (WaveViewer Wv, communication commands table, CAN Editor) ×1




Input modules

ANALOG UNIT
MR8901


VOLTAGE/TEMP UNIT
MR8902


STRAIN UNIT
MR8903


CAN UNIT
MR8904

Logic signal measurement

LOGIC PROBE
9320-01


LOGIC PROBE
MR9321-01


CONVERSION CABLE
9323

Voltage measurement

CONNECTION CORD(600V Max)
L9790


ALLIGATOR CLIP
L9790-01


CONTACT PIN
9790-03


GRABBER CLIP
9790-02


CONNECTION CORD(300V Max)
L9198

High-Voltage measurement

DIFFERENTIAL PROBE
9322


POWER CORD
9328


PT
9303

Current measurement(with the Sensor Unit and the Analog Unit)

noname
CT9279


noname
CT9278


noname
CT9277


CLAMP ON SENSOR
9272-10


SENSOR UNIT
9555-10


CONNECTION CORD(BNC-BNC)
L9217

Current measurement(For commercial power lines)

CLAMP ON PROBE
9018-50


CLAMP ON PROBE
9132-50

Leak current / Load current measurement

클램프온 리크하이테스터
3283


클램프 온 AC/DC하이 테스터
3284


클램프 온 AC/DC하이 테스터
3285

Current measurement(with analog output function also compatible)

AC/DC 클램프 온 하이테스터
3290


CLAMP ON AC/DC SENSOR
9691


CLAMP ON AC/DC SENSOR
9692


CLAMP ON AC/DC SENSOR
9693


OUTPUT CORD
9094


CONVERSION ADAPTER
9199


CARRYING CASE
9400


AC ADAPTER
9445-02


AC ADAPTER
9445-03

PC Software

WAVE PROCESSOR
9335

Removable storage(SD card)

SD MEMORY CARD 2GB
Z4001

Power supply

AC ADAPTER
Z1002


BATTERY PACK
Z1003

Other options

CAN CABLE
9713-01


LAN CABLE
9642


CARRYING CASE
C1004
