| DC Voltage range | 200 mV to 1000 V, 5 ranges, Best accuracy: ±0.025 % rdg. ±2 dgt. |
| AC Voltage range | 2000 mV to 700 V, 4 ranges, Best accuracy: ±0.2 % rdg. ±100 dgt. , Effective value rectifier |
Frequency characteristics
at AC Voltage | 10 to 300 kHz |
| Resistance range | 200 ohm to 100 M-ohm, 7 ranges, Best accuracy: ±0.05 % rdg. ±2 dgt. |
| DC Current range | None |
| AC Current range | (Used with clamp-on sensor range) |
Frequency characteristics
at AC Current | (clamp-on sensor specification) |
| Frequency range | None |
| Continuity | Possible, 50 ohm or less (at 2000 ohm range) |
| Diode check | Possible (6 V open terminal voltage) |
| Other functions | Current measurement (with clamp), Comparator, external input and output, Save/Load function, AVE, trigger, RS-232C, GP-IB ( -01 model ) |
| Range switching | Auto or Manual |
| Display | LED, max. 199999 dgt., max. 999999 dgt. (at Frequency) |
| Sampling rate | 300 times/sec (Fast), 8 to 9 time/sec (Medium), 1 time/sec (Slow) |
| Power supply | 100 to 240 V AC, 50/60 Hz, (specify when ordering) |
| Dimensions, mass | 215 mm(8.46 in)W × 80 mm(3.15 in)H × 265 mm(10.43 in)D, 2.6 kg (91.7 oz) |
| Accessories | TEST LEAD 9170 (1), Power cord (1) |
제품번호 : 3237
