DT4256
ÃÖ´Ù ±â´É žÀç! °í±â´É Å×½ºÅÍ
Á¦Ç°¹øÈ£ : DT4256
Á¦ Ç° ¸í  : DIGITAL MULTIMETER
Á¦Ç°ºÐ·ù : ÇöÀå¿ëÅ×½ºÅͱâ




DC Voltage, ±âº» Á¤È®µµ ¡¾0.3%, AC VÀÇ fƯ¼º 40Hz ~ 1kHz
Á÷Á¢ÀÔ·Â 10A ÃøÁ¤
Àü¾Ð/ÁÖÆļö µ¿½Ã È®ÀÎÀÌ °¡´ÉÇÑ Dual display
low pass filter·Î °íÁ¶ÆÄ ¼ººÐÀ» cut
-25¡É ~ 65¡ÉÀÇ ³ÐÀº »ç¿ë ¿Âµµ ¹üÀ§
PC °èÃø¿¡ ´ëÀÀÇÏ´Â USB Åë½Å ±â´É(option)


  DC Voltage 600.0 mV to 1000 V
5 ranges, Basic accuracy: ¡¾0.3 % rdg. ¡¾3 dgt.
  AC Voltage 6.000 V to 1000 V, 4 ranges, Frequency characteristics: 40 Hz to 1 kHz
Basic accuracy 40 - 500 Hz : ¡¾0.9 % rdg. ¡¾3 dgt. (True RMS, crest factor 3)
  AUTO AC/DCV Yes
  Resistance 600.0 ¥Ø to 60.00 M¥Ø, 6 ranges, Basic accuracy: ¡¾0.7 % rdg. ¡¾3 dgt.
  DC Current 60.00 mA to 10.00 A, 4 ranges,
Basic accuracy: ¡¾0.9 % rdg. ¡¾3 dgt.
  AC Current 600.0 mA to 10.00 A, 3 ranges,
Basic accuracy 40 - 500 Hz : ¡¾1.4 % rdg. ¡¾3 dgt.
(True RMS, crest factor 3, 40 Hz to 1 kHz)
  AC Current (use with Clamp on probes) 10.00 A to 1000 A, 7 ranges, Add the Clamp on probe accuracy to basic accuracy
40 - 1 kHz : ¡¾0.9 % rdg. ¡¾3 dgt. (True RMS, crest factor 3)
  Voltage detection Hi: AC40 V to 600 V, Lo: AC80 V to 600 V
  C (capacitance) 1.000 ¥ìF to 10.00 mF, 5 ranges, Basic accuracy: ¡¾1.9 % rdg. ¡¾5 dgt.
  Frequency 99.99 Hz to 99.99 kHz, 4 ranges (limited by the minimum detectable voltage),
Basic accuracy: ¡¾0.1 % rdg. ¡¾1 dgt.
  Continuity check Continuity threshold [ON]: 25 ¥Ø or less ,
[OFF]: 245 ¥Ø or more,
'Response time: 0.5 ms or more
  Diode test Open terminal voltage: 5.0 V or less, Testing current 0.5 mA or less,
Threshold of forward voltage: 0.15 V to 1.5 V
  Other functions Filter function, Display value hold, Auto hold, Max/Min/Average value display,
Relative display, Auto-power save, USB communication (option)
  Display Main and Sub displays: 4-digits LCD, max. 6000 digits, bar graph
  Display refresh rates 5 tim5 times/s (Capacitance measurement: 0.05 to 5 times/s, depending on measured value, Frequency: 1 to 2 time/s)
  Power supply LR03 alkaline batteries ¡¿4, Continuous use: 130 hours (backlight OFF)
  Dimensions and mass 84 mm (3.31 in)W ¡¿ 174 mm (6.85 in)H¡¿ 52 mm (2.05 in)D,
390 g (13.8 oz) (including batteries and holster)
  Accessories Test lead L9207-10 ¡¿1, Holster ¡¿1, Instruction manual ¡¿1, LR03 alkaline battery ¡¿4





Test leas

SMALL ALLIGATOR CLIP SET
L4934


CONTACT PIN SET
L4933


TEST LEAD
L9207-10

Current measurement

CLAMP ON PROBE
9010-50


CLAMP ON PROBE
9018-50


CLAMP ON PROBE
9132-50


CONVERSION ADAPTER
9704

Options for Test leads

GRABBER CLIP
9243


CONNECTION CABLE SET
L4930


EXTENSION CABLE SET
L4931


TEST PIN SET
L4932


SMALL ALLIGATOR CLIP SET
L4934


ALLIGATOR CLIP SET
L4935


BUS BAR CLIP SET
L4936


MAGNETIC ADAPTER SET
L4937


TEST PIN SET
L4938


BREAKER PIN SET
L4939

Other options

CARRYING CASE
C0202


COMMUNICATION PACKAGE(USB)
DT4900-01


MAGNETIC STRAP
Z5020
